Precise Error Measurement Electronic Bit Error Rate Tester With 1.25-15Gbps Data Rate

Product Description

Bit Error Rate Tester(BERT)

JHBF BERTWaveE415A BERT are designed to test cables and diagnose signal problems in the communication field. 4-channel standard
multi-rate between 1.25Gbps and 15Gbps are provided for signal conditioning and BER analysis.
BERTWaveE415ABERT are high reliability and cost effective. That is fully featured for lab and production testing of
systems, components, and EIectro-Optical Modules.

Features

* 4-channel standard, clock in/out and trigger signal
* Multi-rate: 1.25/2.13/2.48/3.13/4.25/4.98/5G/6.25/8.5/9.95/10/10.31/10.52/10.71/11.09/11.3/12.5/14.03/15Gbps
* Patterns: PRBS7/9/15/23/31 ,8:8bit square, user define
* High speed trigger output
* Support test time setting
* Support touch screen operation
* With USB/console/ETH interface, it can be configured by computer

Applications

It can be widely used in lab and production testing for optical transceiver, communication IC and cables.
* CFP2/CFP4/QSFP28/SFP28/QSFP+/SFP+/SFP/AOC optical transceiver design and test.
* Communication IC test
* Communication Cable test

Specification

Parameter	Min	TYP.	Max	Note
Data rate (Gbps)	5		60	4 lanes work together
Rising Time(ps)	18	20	30	10.3125Gbps,20%-80%
Falling Time(ps)	18	20	30	10.3125Gbps,20%-80%
Patterns	2N -1(N=7/9/15/23/31),8:8 bit square,user define	NRZ
RMS(ps)	1.2	1.5	2.5	10.3125Gpbs
PP(ps)	8	11	15	10.3125Gpbs
Ext Clk Input Duty Cycle(%)	45%	50%	55%
Clk Output Frequency(Mbps)		212.5～353.7
DataOutput Amplitude(mV)	50	350	600
DataIutput Amplitude(mV)	40	～	425
Supply Voltage(V)		AC100～240,50/60Hz
Operating Temp(℃)	0		40

Certifications

ISO9001 Quality Management System Certificate

ISO14000 Environmental Management System Certificate

ISO18000 Occupational Health And Management System Certificate

Trade Mark-JHBF

Registration for foreign trade

Certificate of Credit Rating-AAA

Network License of CWDM

Network License of DWDM

Network License of OTN

Patent- SFP optical power meter

Patent-An optical module support optical line protection

Patent-QSFP optical power meter

Software copyright- Embedded software for optical network equipment

Software Copyright-General software for Optical module

Software Copyright-SCM software for mini SFP/QSFP Optical powermeter

Software Copyright-APP for mini SFP/QSFP optical power meter

Software Copyright-NMS for optical fiber sensing equipment

Software Copyright-NMS for optical transport network fiber equipment
